Design Of Novel Coaxial High Pass Filter

4 min read

High pass LC filter design encompasses a range of different filter variants that can be used depending on the specifications for in-band ripple, final roll-off rate, and other factors. The constant-k form is used here, which results in some basic equations:

The section can be determined using the equations below and the multipliers 2L and C shown in the diagram .Analytically and numerically, the complete specification of a high-power coaxial high-pass filter is provided. The coaxial structure is made up of two hollow concentric cylinders connected at a single azimuthal angle by a septum. This septum mechanically holds two hollow cylinders together and offers strong high pass filter characteristics. This structure has a much sharper attenuation slope in the stop band than current filter configurations. This makes for a smoother transition from stop to pass band. The coaxial structure has one end that is closed and the other end that is used as an output port. The excitation port is situated on the outside cylinder’s side walls. To obtain a filter configuration at UHF, the design technique suggested in this paper was used. A 3D electromagnetic simulator is used to simulate the new filter. The results are then compared to the results that were calculated. The simulated and calculated results were found to be in good agreement.

Precautions in filter design and construction

A few instructions, hints, and tips can be integrated into the design and development of a high pass filter to ensure that it meets the design criteria and works as close to theoretically as possible.

Filter parts that cascade for better attenuation: It is possible to cascade multiple filter sections in the high pass filter to have a greater slope or roll off. As this is finished, adjacent sections’ filter elements can be merged. If two T section filters are cascaded, and each T section has a 1 H inductor in each leg of the T, the inductors in the adjoining sections can be combined and a 2 H inductor used.

Using components with tight tolerances: Component selection is crucial for any filter, but particularly for a high pass filter. To ensure that the necessary output is achieved, near tolerance components should be used. Temperature stability must also be tested to ensure that the filter components do not change significantly with temperature, affecting performance.

Layout of the filter: The architecture of the filter must be carefully considered, particularly when it is used for high frequencies. The key elements that degrade the filter output are capacitive and inductive coupling. As a consequence, the filter’s input and output should be kept apart. Components from adjacent filter sections should be spaced apart, and short leads and tracks should be used. Where appropriate, displays were used, as well as high-quality connectors and coaxial cable at the input and output.

This design makes creating an LC high pass filter quick and manageable. The design can be measured and realised using simple equations.

There are many guidelines and tips to follow when designing and creating a bandpass filter to achieve the best results.



Component selection: The components used in any RF filter are crucial to its performance. It’s even more important for a bandpass filter because the circuit has six components instead of only three in a similar low pass or high pass LC filter. As a result, components with tight tolerances should be used to ensure that the desired output is achieved. Temperature stability must also be tested to ensure that the RF filter components do not change drastically with temperature, affecting performance.

Layout of the filter: Any RF filter, including a high pass filter, may have a number of components.

The architecture of the RF filter must be carefully considered, particularly when the RF filter is used for high frequencies. The key elements that degrade the filter output are capacitive and inductive coupling. As a consequence, the filter’s input and output should be kept apart. Components from adjacent filter sections should be spaced apart, and short leads and tracks should be used. Where appropriate, displays were used, as well as high-quality connectors and coaxial cable at the input and output.



The high pass filter circuit is simple to create, and the design equations make calculating the circuit values a breeze. Although the performance might not be ideal for all applications, it is an excellent option for many RF LC-based high pass filters.
